ASI 0349 Counter Mounted Soap Dispenser

Home > Soap Dispensers > Wall Mounted >

ASI 0349 Counter Mounted Foot Operated Surgical Liquid Soap Dispenser, 32 oz

ASI 0349 Counter Mounted Soap Dispenser image

List Price: $65.60

Our Price: $36.10

Savings: $29.50

Manufacturer: ASI
Availability: Usually Ships in 2-3 Business Days

Product Code: 0349

Qty:

Description

Technical Specs

A Note from the Manufacturer

ASI 0349 Counter Mounted Foot Operated Surgical Liquid Soap Dispenser, 32 oz

Soap Recommendation
Liquid Soap
pH Range: 5.0-9.0
Viscosity Range mPas-cP: 50-2500

Construction
Foot operated surgical soap dispenser has a neoprene foot pump with anti slip base. A rotatable spout fabricated of Type 316 stainless steel. The dispenser housing with check valve is made of chemically resistant ABS plastic and soap container is fabricated of chemically resistant polyethylene.
Capacity: 32 oz.

Installation
Unit is surface mounted to a wall or partition using No. 10 self tapping screws (supplied) through holes provided in wall bracket into metal inserts in valve housing.

For maximum usability and compliance with ADA Accessibility Guidelines, install unit so that spout is 48" max AFF (above finished floor) or 46" AFF with side reach over an obstruction.

Recommended installation is 42" AFF or 16" max above wash basin.

Operation
Soap is manually dispensed when the foot pump is depressed. Unit can be refilled by unscrewing soap tank from valve housing. The translucent tank allows easy viewing of soap levels and may be refilled at any time.

Warranty
One (1) Year Manufacturer's Warranty - Warranted to be free of defects in material or workmanship for one (1) year from date of sale.
