ASI A0247-TRBS TRI-Umph™ Dryer Wall Protector Ceramic Backsplash and Mounting Frame
ASI A0247 Wall Protector image

Large Quantity, Item Customization, or Government Project? Request A Quote or give us a call at 920-569-0895
List Price: $118.20
Our Price: $65.00
Savings: $53.20
Manufacturer: ASI
Availability: Usually Ships in 5-7 Business Days


Free Shipping
Product Code: A0247-TRBS
Qty:

Description Technical Specs

ASI A0247-TRBS TRI-Umph™ Dryer Wall Protector Ceramic Backsplash and Mounting Frame
For use with ASI's TRI-Umph™ hand dryer; models 20200 and 20201

Construction
Wall protector backsplash plate with mounting frame has a black powder coated 20 gauge steel frame for surface mounting with eight (8) screws (by others). The absorptive evaporator plate is 9/32" thick and has a face finish of medium matte gray to match the TRI-Umph hand dryer. The frame is formed from one piece of steel and has no exposed seams or welded joints. it has four (4) exposed mounting tabs formed from the frame edges. Only the gray face is visible inside the frame.

Installation
Mount unit on wall surface using eight (8) No. 8 self-tapping screws (by others) through exposed 3/16" diameter mounting holes into appropriately prepared anchors (by others). Center the unit directly behind the hand chamber of ASI Model № 20200/20201 TRI-Umph™ hand dryer.

Operation
Plate absorbs water droplets that may get past the absorptive ceramic evaporator plate on ASI Model 20200 TRI-Umph™ hand dryer. Plate continuously evaporates water at a rate matching the absorption of castoff droplets from hand dryer usage. Water cast-off droplets absorbed and subsequently evaporated from plate are prevented from soaking into wall finish behind. Plate may be cleaned at the same time as the dryer unit following instructions found in the dryer Owner Manual.

Accessories
ASI 20200 TRI-umph™ Surface Mtd High Speed Hand Dryer w/ Filter System, Silver, GreenSpec ASI 20201 TRI-umph™ Surface Mtd High Speed Hand Dryer w/ Filter System, White, GreenSpec
