Construction
Recessed hand dryer has one piece 1/8" thick white iron casting cover cover finished in high gloss, acid resistant, multicoat vitreous enamel. The cover is equipped with tow position, self returning, chrome plated air outlet nozzle and secures to the base unit with two (2) concealed, vandal resistant, recessed hex screws. The recessed mounting box is 16 gauge steel with baked enamel finish and rust resistant. The base unit is one piece aluminum casting that incorporates concealed, vandal resistant air inlet vanes on both sides and bottom. The motor is universal, 1/10 hp, 6200 rpm on resilient mounting. It is equipped with an automatic thermal overload switch. The single inlet centrifugal fan is dynamically balanced mounted on motor shaft. It directs air flow through the coiled nickel chrome heating element. Heating element is inaccessible to vandals.
Installation
Wall Preparation: Provide framed rough wall opening 13-3/4'' wide x 9-1/2'' high (350 x 240mm). Minimum recessed depth
required to finish face of wall is 3-3/4'' (95mm). Allow clearance for construction features that may protrude into rough wall
opening from opposite wall. Coordinate with mechanical engineer to avoid pipes, vents, and conduits. If installed in plaster wall,
it is recommended that opening be grounded on all four sides with metal plaster trim. If unit projects above top of wainscot,
provide aluminum channel or other filler to eliminate gap between flange of mounting box and finish face of wall. If two units
are installed back-to-back, a sound-barrier is recommended between units. Provide shims between framing and mounting box
at all points indicated by an S, then secure with four #10 (M4.8) screws (not furnished). Provide electrical service from nearest
distribution panel to recessed mounting box in conformance with local electrical codes.
Wiring Instructions:
1. For 115-Volt Dryers — Connect ground wire to ground terminal marked , the black or hot wire to terminal marked
L1, and neutral or white wire to terminal marked N. A DEDICATED LINE IS REQUIRED FOR EACH 115-VOLT
INSTALLATION.
2. For 208–240-Volt Dryers — Connect ground wire to ground terminal marked and the 208- or 240-volt wires to terminals
marked L1 and L2.
Notes: Electronic sensor in AutoPilot dryers will pick up movement within 7-1/2'' (190mm) of air-outlet nozzle. Use caution
when choosing location for AutoPilot dryers in confined areas. Consider proximity to doorways and other traffic areas.
Bobrick automatic hand dryers should be installed at least 15" (380mm) above any projection or horizontal surface which may
interfere with the operation of the automatic sensor.
Operation
User activates dryer by placing hands under sensor. Dryer automatically shuts off after time-out when user removes hands
from sensor activation zone.
Warranty
In addition to Bobrick's one-year guarantee, Bobrick extends a limited 10-year warranty from
the date of purchase for AutoPilot hand and hair dryers on all parts, except motor brushes, to the original owner of the installed
unit against defects in factory workmanship or material under normal use and service. Motor brushes are warranted for three
years from date of purchase. This warranty is limited to the repair or exchange of defective parts at the option of Bobrick.
|
